ABB ACS560 User Manual

108 Control macros
3-wire macro
This macro is used when the drive is controlled using momentary push-buttons. It provides three
constant speeds. To enable the macro, select it in the Primary settings menu or set parameter
96.04 Macro select to 3-wire.
To enable the macro, navigate to
• Main menu  Connection macro  3-wire macro
or
Main menu
 Complete parameter list parameter 96.04 Macro select [17]
3-wire.

ABB ACS560 Specifications

General

Frequency	50/60 Hz
Control Method	Scalar control
Protection Features	Overcurrent, overvoltage, undervoltage, short circuit
Communication Interfaces	Modbus RTU, Profibus DP, CANopen, Ethernet/IP
Enclosure Rating	IP21
Ambient Temperature	-10 to +50 °C
Input Voltage	380 to 480 V AC
Cooling Method	Air cooling (natural convection or forced ventilation)
