Parameters 291
Class 30 Class 30 relay trip class 3
Class 40 Class 40 relay trip class 4
36
36 Load analyzer
Peak value and amplitude logger settings.
See also section Load analyzer (page 94).
36.01 PVL signal source Selects the signal to be monitored by the peak value logger.
The signal is filtered using the filtering time specified by
parameter 36.02 PVL filter time.
The peak value is stored, along with other pre-selected
signals at the time, into parameters 36.10…36.15.
The peak value logger can be reset using parameter 36.09
Reset loggers. The logger is also reset whenever the signal
source is changed. The date and time of the last reset are
stored into parameters 36.16 and 36.17 respectively.
Motor current
Not selected None (peak value logger disabled). 0
Motor speed used 01.01 Motor speed used (page 165). 1
Output frequency 01.06 Output frequency (page 165). 3
Motor current 01.07 Motor current (page 165). 4
Motor torque 01.10 Motor torque (page 165). 6
DC voltage 01.11 DC voltage (page 165). 7
Output power 01.14 Output power (page 166). 8
Speed ref ramp in 23.01 Speed ref ramp input (page 226). 10
Speed ref ramp out 23.02 Speed ref ramp output (page 226). 11
Torque ref used 26.02 Torque reference used (page 235). 13
Freq ref used 28.02 Frequency ref ramp output (page 240). 14
Process PID out 40.01 Process PID output actual
(page 295). 16
Other Source selection (see Terms and abbreviations on page 162). -
36.02 PVL filter time Peak value logger filtering time. See parameter 36.01 PVL
signal source.
2.00 s
0.00…120.00 s Peak value logger filtering time. 100 = 1 s
36.09 Reset loggers Resets the peak value logger and/or amplitude logger 2.
(Amplitude logger 1 cannot be reset.)
Done
Done Reset completed or not requested (normal operation). 0
PVL Reset the peak value logger. 2
36.10 PVL peak value Peak value recorded by the peak value logger. 0.00
-32768.00…
32767.00
Peak value. 1 = 1
36.11 PVL peak date The date on which the peak value was recorded. 1/1/1980
1/1/1980...6/5/2159 Peak occurrence date. -
36.12 PVL peak time The time at which the peak value was recorded. 00:00:00
00:00:00...23:59:59 Peak occurrence time. -
36.13 PVL current at peak Motor current at the moment the peak value was recorded. 0.00 A
-32768.00…
32767.00 A
Motor current at peak. 1 = 1 A
No. Name/Value Description Def/FbEq16
