R5906848 /04 DP2K SLP Series104
How to clean the Prism exit side?
1. Wipe off the dust of the Prism exit. Use for that a dry and clean Lens cleaning cloth.
Tip: Limit the number of wipe movements. This to protect the optical coating. It is better to wipe off the
dust with one good wipe movement than with 10 soft wipe movements.
2. Is all dust removed from the Prism exit?
► If yes, stop this cleaning procedure.
► If no, wipe off the dust of the Prism exit with lens cleaner and a clean lens cleaning cloth. Polish again with a
dry one.
9.7 Replacement of the fan of the Light Processor
compartment
To access the fan of the Light Processor compartment the top cover and the top cover plate have to
be removed from the projector. This procedure assumes that the top cover and top cover plate are
already removed from the projector.
Required tools
3mm Allen wrench.
How to replace the fan of the Light Processor compartment?
1. Disconnect the wire of the fan (reference 5 Image 9-16) and the wire of the temperature sensor (reference
6Image 9-16) from the Signal Backplane.
2. Remove the fan assembly from the projector chassis. Note that the fan assembly is engaged with four
mounting pins (reference 8 Image 9-15).. Pull the fan assembly a few mm upwards and then away from the
projector chassis.
