R5906848 /04 DP2K SLP Series112
5. Guide the wire of the fan through the cable clamp (reference 8 Image 9-27) and mark the wire by attaching a
blue colored cable tie two centimeters from the plug (reference 9 Image 9-27).
6. Install the fan assembly onto the projector chassis. Use a 3mm Allen wrench to fasten the two screws
(reference 4Image 9-26).
7. Connect the wire of the fan with the blue marked socket on the Signal Backplane. (reference 1 Image 9-25)
9.11 Authorization to clear security warning on the
projector
When is an authorization required to clear the security warning?
If a module has been removed or if the sealed compartment has been opened, an authorization will be
required to clear the security warning.
Required tools
Authorization pin code.
Authorization procedure to clear security warning
1. Ensure that all modules are properly installed.
2. Start up the projector (Standby mode).
3. Initiate authorization by pushing the Key button on the Local Keypad:
The color of the backlight of the Numeric keys 1 to 6 of the Local Keypad changes from blue to yellow.
4. Enter pin code within 5 seconds.
• In case no keys are pressed, the color of the backlight of the Numeric keys 1 to 6 changes back to blue.
• In case of an incorrect code entry, the color of the backlight of the Numeric keys changes to red for 1
second and then back to blue.
• In case of a correct code entry, the color of the backlight of the Numeric keys 1 to 6 changes to green for
1 second and then back to blue.
Each attempt to clear the security warning and its result (successfully or unsuccessfully) is logged
inside the projector.
