7.1 Overview
Overview
2 3
4
1
Image 7-1
1 Light Source Fan Interconnection Board
2 Controller Assembly
3 Cooling Liquid reservoir
4 Blue Laser Interconnection Board
5
6
9
10
7
8
Image 7-2
5 Fan assembly
6 Phosphor Wheel Monitoring Interconnection
Board
7 Phosphor Wheel Interconnection Board
8 Light Sensor Interconnection Board
9 Combiner unit
10 Phosphor wheel
Laser Phosphor Light Source
