About this chapter

This chapter describes how to replace the complete Lens Holder or single parts of the Lens Holder like the

motors for lens shift. Note that the motors for the shift functionality are built into the Lens Holder. The motors

for zoom and focus functionality are built into the Lens. Lens cleaning procedure is also included in this

chapter. Not included in this chapter are the adjustment procedures for the Lens Holder (Scheimpflug and

Back Focal Length), for that see chapter “Scheimpflug”, page 199.

CAUTION: Never transport the projector with a Lens mounted in the Lens Holder. Always remove

the Lens before transporting the projector. Neglecting this can damage the Lens Holder and Prism.

CAUTION: Caution when removing or installing the lens! Fragile parts at the inner side of the Lens

Holder.

Each time a lens is manipulated (e.g. removed and installed in a projector), it needs to be homed

and returned.

Overview

•

Introduction Lens Holder

• Available lenses

• Lens selection

• Lens installation

• Lens removal

• Lens shift, zoom & focus

• Removal of the Lens Holder cover plate

• Removal of the Lens Holder

• Installing the Lens Holder

• Installation of the Lens Holder cover plate

• Replacement of the Vertical Shift stepper motor

• Replacement of the Horizontal Shift stepper motor

• Replacement of the motor assembly for 0.69" DC2K lenses (Type 'M')

• Replacement of the motor assembly for 0.69" DC2K lenses (Type 'F')

• Replacement of the motor assembly for 0.69" DC2K lenses (Type 'B')

• Replacement of the Inner Dust Rubber
