Chapter 15 Configuring Private VLANs
Configuring Private VLANs
This example shows how to configure interface FastEthernet 5/1 as a private VLAN host port and verify
the configuration:
Router# configure terminal
Router(config)# interface fastethernet 5/1
Router(config-if)# switchport mode private-vlan host
Router(config-if)# switchport private-vlan host-association 202 303
Router(config-if)# end
Router# show interfaces fastethernet 5/1 switchport
Name: Fa5/1
Switchport: Enabled
Administrative Mode: private-vlan host
Operational Mode: down
Administrative Trunking Encapsulation: negotiate
Negotiation of Trunking: On
Access Mode VLAN: 1 (default)
Trunking Native Mode VLAN: 1 (default)
Administrative private-vlan host-association: 202 (VLAN0202) 303 (VLAN0303)
Administrative private-vlan mapping: none
Operational private-vlan: none
Trunking VLANs Enabled: ALL
Pruning VLANs Enabled: 2-1001
Capture Mode Disabled
Configuring a Layer 2 Interface as a Private VLAN Promiscuous Port
To configure a Layer 2 interface as a private VLAN promiscuous port, perform this task:
Step 4
Router(config-if)# switchport private-vlan
host-association
primary_vlan_ID
secondary_vlan_ID
Associates the Layer 2 port with a private VLAN.
Router(config-if)# no switchport private-vlan
host-association
Clears the association.
Step 5
Router(config-if)# end
Exits configuration mode.
Step 6
Router# show interfaces [ type
1
slot/port ]
switchport
Verifies the configuration.
1. type = ethernet, fastethernet, gigabitethernet, or tengigabitethernet
Command Purpose
Command Purpose
Step 1
Router(config)# interface type
1
slot/port
Selects the LAN interface to configure.
Step 2
Router(config-if)# switchport
Configures the LAN interface for Layer 2 switching:
• Yo u m us t e n te r t he switchport command once
without any keywords to configure the LAN interface
as a Layer 2 interface before you can enter additional
switchport commands with keywords.
• Required only if you have not entered the switchport
command already for the interface.
