1-2
Cisco 7600 Series Router Cisco IOS Software Configuration Guide, Release 12.2SX
OL-4266-08
Chapter 1 Product Overview
Configuring Embedded CiscoView Support
Configuring Embedded CiscoView Support
These sections describe configuring Embedded CiscoView support:
• Understanding Embedded CiscoView, page 1-2
• Installing and Configuring Embedded CiscoView, page 1-2
• Displaying Embedded CiscoView Information, page 1-3
Understanding Embedded CiscoView
The Embedded CiscoView network management system is a web-based interface that uses HTTP and
SNMP to provide a graphical representation of the router and to provide a GUI-based management and
configuration interface. You can download the Java Archive (JAR) files for Embedded CiscoView at
this URL:
http://www.cisco.com/cgi-bin/Software/CiscoView/cvplanner.cgi
Installing and Configuring Embedded CiscoView
To install and configure Embedded CiscoView, perform this task:
Note The default password for accessing the router web page is the enable-level password of the router.
Command Purpose
Step 1
Router# dir device_name
Displays the contents of the device.
If you are installing Embedded CiscoView for the first
time, or if the CiscoView directory is empty, skip to
Step 4.
Step 2
Router# delete device_name :cv/*
Removes existing files from the CiscoView directory.
Step 3
Router# squeeze device_name :
Recovers the space in the file system.
Step 4
Router# archive tar /xtract tftp://
ip_address_of_tftp_server /ciscoview.tar
device_name :cv
Extracts the CiscoView files from the tar file on the TFTP
server to the CiscoView directory.
Step 5
Router# dir device_name :
Displays the contents of the device.
In a redundant configuration, repeat Step 1 through
Step 5 for the file system on the redundant supervisor
engine.
Step 6
Router# configure terminal
Enters global configuration mode.
Step 7
Router(config)# ip http server
Enables the HTTP web server.
Step 8
Router(config)# snmp-server community string ro
Configures the SNMP password for read-only operation.
Step 9
Router(config)# snmp-server community string rw
Configures the SNMP password for read/write operation.
