42-31
Cisco 7600 Series Router Cisco IOS Software Configuration Guide, Release 12.2SX
OL-4266-08
Chapter 42 Configuring PFC3BXL or PFC3B Mode MPLS QoS
Configuring PFC3BXL or PFC3B Mode MPLS QoS
Configuring EXP Value Maps
These sections describe how EXP values are mapped to other values:
• Configuring an Ingress-EXP to Internal-DSCP Map, page 42-31
• Configuring a Named Egress-DSCP to Egress-EXP Map, page 42-31
Configuring an Ingress-EXP to Internal-DSCP Map
To configure an ingress-EXP to internal-DSCP map, perform this task:
This example shows how to configure an ingress-EXP to internal-DSCP map:
Router(config)# mls qos map exp-dscp 43 43 43 43 43 43 43 43
Router(config)#
This example shows how to verify the configuration:
Router(config)# show mls qos map exp-dscp
Exp-dscp map:
exp: 0 1 2 3 4 5 6 7
------------------------------------
dscp: 43 43 43 43 43 43 43 43
Configuring a Named Egress-DSCP to Egress-EXP Map
To configure a named egress-DSCP to egress-EXP map, perform this task:
This example shows how to configure a named egress-DSCP to egress-EXP map:
Router(config)# mls qos map dscp-exp 20 25 to 3
Router(config)#
Command Purpose
Step 1
Router(config)# mls qos map exp-dscp
values
Configures the ingress-EXP value to internal-DSCP map.
You must enter eight DSCP values corresponding to the
EXP values. Valid values are 0 through 63.
Router(config)# no mls qos map exp-dscp
Reverts to the default map.
Step 2
Router(config)# end
Exits configuration mode.
Step 3
Router# show mls qos maps
Verifies the configuration.
Command Purpose
Step 1
Router(config)#
mls qos map dscp-exp
dscp_values
to
exp_values
Configures a named egress-DSCP to egress-EXP map.
You can enter up to eight DSCP values at one time to a
single EXP value. Valid values are 0 through 7.
Router(config)# no mls qos map dscp-exp
Reverts to the default map.
Step 2
Router(config)# end
Exits configuration mode.
Step 3
Router# show mls qos maps
Verifies the configuration.
