22-9
Cisco 7600 Series Router Cisco IOS Software Configuration Guide, Release 12.2SX
OL-4266-08
Chapter 22 Configuring Layer 3 Interfaces
Configuring AppleTalk Routing, Cable Ranges, and Zones
This example shows how to enable IPX routing and assign an IPX network address to interface
VLAN 100:
Router# configure terminal
Enter configuration commands, one per line. End with CNTL/Z.
Router(config)# ipx routing
Router(config)# ipx router rip
Router(config-ipx-router)# network all
Router(config-ipx-router)# interface vlan 100
Router(config-if)# ipx network 100 encapsulation snap
Router(config-if)# no shutdown
Router(config-if)# end
Router# copy running-config startup-config
Configuring AppleTalk Routing, Cable Ranges, and Zones
For complete information and procedures, refer to these publications:
• Cisco IOS AppleTalk and Novell IPX Configuration Guide, Release 12.2, at this URL:
http://www.cisco.com/en/US/docs/ios/12_2/atipx/configuration/guide/fatipx_c.html
• Cisco IOS AppleTalk and Novell IPX Command Reference, Release 12.2, at this URL:
http://www.cisco.com/en/US/docs/ios/12_2/atipx/command/reference/fatipx_r.html
To configure routing for AppleTalk, perform this task beginning in global configuration mode:
This example shows how to enable AppleTalk routing and assign an AppleTalk cable-range and zone
name to interface VLAN 100:
Router# configure terminal
1. type = ethernet, fastethernet, gigabitethernet, or tengigabitethernet, or ge-wan
Command Purpose
Step 1
Router(config)# appletalk routing
Enables AppleTalk routing.
Step 2
Router(config)# interface {vlan vlan_ID } |
{
type
1
slot/port } | {port-channel
port_channel_number }
1. type = ethernet, fastethernet, gigabitethernet, or tengigabitethernet, or ge-wan
Selects an interface to configure.
Step 3
Router(config-if)# appletalk cable-range
cable_range
Assigns a cable range to the interface.
Step 4
Router(config-if)# appletalk zone zone_name
Assigns a zone name to the interface.
Step 5
Router(config-if)# no shutdown
Enables the interface.
Step 6
Router(config-if)# end
Exits configuration mode.
Step 7
Router# show interfaces [{vlan vlan_ID } |
{
type
1
slot/port } | {port-channel
port_channel_number }]
Router# show appletalk interfaces [{vlan
vlan_ID }
| {
type
1
slot/port } | {port-channel
port_channel_number }]
Router# show running-config interfaces [{vlan
vlan_ID } | { type
1
slot/port } | {port-channel
port_channel_number }]
Verifies the configuration.
