CHAPTER
5-1
Cisco 7600 Series Router Cisco IOS Software Configuration Guide, Release 12.2SX
OL-4266-08
5
Configuring a Supervisor Engine 32
This chapter describes how to configure a Supervisor Engine 32 in a Cisco 7600 series router. This
chapter contains these sections:
• Flash Memory on a Supervisor Engine 32, page 5-2
• Supervisor Engine 32 Ports, page 5-2
Note • For complete syntax and usage information for the commands used in this chapter, refer to the Cisco
IOS Master Command List, Release 12.2SX at this URL:
http://www.cisco.com/en/US/docs/ios/mcl/122sxmcl/12_2sx_mcl_book.html
• With Cisco IOS software, this is the minimum required Supervisor Engine 32 memory:
– 512 MB DRAM on the Supervisor Engine 32
– 512 MB DRAM on the MSFC2A
• Supervisor Engine 32 has a PFC3B and operates in PFC3B mode.
• The Supervisor Engine 32 is supported in the WS-6503 and WS-6503-E (3-slot) chassis, but not the
CISCO7603 chassis.
• With a 3-slot or a 4-slot chassis, install the Supervisor Engine 32 in either slot 1 or 2.
• With a 6-slot or a 9-slot chassis, install the Supervisor Engine 32 in either slot 5 or 6.
• With a 13-slot chassis, install the Supervisor Engine 32 in either slot 7 or 8.
• Supervisor Engine 32 does not support switch fabric connectivity.
• For information about the hardware and software features supported by the Supervisor Engine 32,
see the Release Notes for Cisco IOS Release 12.2SX on the Supervisor Engine 720,
Supervisor Engine 32, and Supervisor Engine 2.
Tip For additional information (including configuration examples and troubleshooting information), see the
documents listed on this page:
http://www.cisco.com/en/US/products/hw/routers/ps368/tsd_products_support_series_home.html
