28-23
Cisco 7600 Series Router Cisco IOS Software Configuration Guide, Release 12.2SX
OL-4266-08
Chapter 28 Configuring IPv4 Multicast Layer 3 Switching
Configuring IPv4 Bidirectional PIM
(10.1.0.17, 224.2.2.17) Incoming interface: Vlan10, Packets switched: 3340
Hardware switched outgoing interfaces:
MFD installed: Vlan10
(10.1.0.13, 224.2.2.13) Incoming interface: Vlan10, Packets switched: 0
Hardware switched outgoing interfaces:
This example shows how to display the IP multicast Layer 3 switching statistics:
Router# show mls ip multicast statistics
MLS Multicast Operation Status:
MLS Multicast configuration and state:
Router Mac: 00e0.b0ff.7b00, Router IP: 33.0.33.24
MLS multicast operating state: ACTIVE
Shortcut Request Queue size 4
Maximum number of allowed outstanding messages: 1
Maximum size reached from feQ: 3096
Feature Notification sent: 1
Feature Notification Ack received: 1
Unsolicited Feature Notification received: 0
MSM sent: 205170
MSM ACK received: 205170
Delete notifications received: 0
Flow Statistics messages received: 35211
MLS Multicast statistics:
Flow install Ack: 996508
Flow install Nack: 1
Flow update Ack: 1415959
Flow update Nack: 0
Flow delete Ack: 774953
Complete flow install Ack: 958469
Router#
Configuring IPv4 Bidirectional PIM
These sections describe how to configure IPv4 bidirectional protocol independent multicast (PIM):
• Enabling IPv4 Bidirectional PIM Globally, page 28-23
• Configuring the Rendezvous Point for IPv4 Bidirectional PIM Groups, page 28-24
• Setting the IPv4 Bidirectional PIM Scan Interval, page 28-24
• Displaying IPv4 Bidirectional PIM Information, page 28-25
Enabling IPv4 Bidirectional PIM Globally
To enable IPv4 bidirectional PIM, perform this task:
This example shows how to enable IPv4 bidirectional PIM on the router:
Router(config)# ip pim bidir-enable
Router(config)#
Command Purpose
Router(config)# ip pim bidir-enable
Enables IPv4 bidirectional PIM globally on the router.
Router(config)# no ip pim bidir-enable
Disables IPv4 bidirectional PIM globally on the router.
