Serial port Advanced RealPort configuration without using the Digi Navigator
Digi Connect EZ Mini User Guide
166
n RS-422
l Enable Termination if you want to enable electrical termination on this serial port.
n RS-485
l Enable Termination if you want to enable electrical termination on this serial port.
l Enable Full Duplex if you want to enable full duplex communication on this serial
port.
The default is RS-232.
9. Expand Logging Settings to configure logging for this serial port.
a. To enable logging, click to toggle on Enable.
b. In the Log file name field, enter a descriptive name for the log file.
c. For Log file size, type the size of the log file. When the log file reaches the size limit, the
current file is saved and a new file is created. The default is 65536 bytes.
d. From the Type of data to log list box, specify the type of data that should be saved.
n Received
n Transmitted
n Both
n Both with arrows. This is the default.
e. If you want to log the time at which date was received or transmitted, click the
Timestamps toggle to Enable.
f. If you want to log the data as hexadecimal values, click the Hexadecimal toggle to Enable.
Note You can review the message log in the Serial Port Log page. See Review the serial
port message log.
10. Click Apply to save the configuration and apply the change.
Command line
1. Select the device in Remote Manager and click Actions > Open Console, or log into the
Connect EZ local command line as a user with full Admin access rights.
Depending on your device configuration, you may be presented with an Access selection
menu. Type admin to access the Admin CLI.
2. At the command line, type config to enter configuration mode:
> config
(config)>
3. The serial port is enabled by default. To disable:
(config)> serial port1 enable false
(config)>
4. Set the mode:
(config)> serial port1 mode realport
(config)>
