3.1 Web MMI
3-3
3.1.2 Web MMI Menu
Navigation
Bar Menu
Menu Contents area Items-1 Items-2 Note
Satellite APAC, EMEA, AMER
The name of the satellite currently being
searched or already acquired will be displayed.
The name of the satellites can be changed via;
Settings -> Basic Settings -> Satellite.
Channel Primary, Alternate Global Channel will be displayed.
Status
Search, Tune, Track,
Blocking
The satellite capturing status will be displayed.
Antenna elevation xx [degree]
Tracking states
Signal strength xx [dB/Hz]
St-by: Regional Beam
Comm.: Spot beam
Using GPS Internal, External Internal > External
Latitude
Ship position info
Longitude
deg.min.sec
Error xx
Current error
Warning xx
The number of errors currently issued will be
displayed.
This will be reflected upon “Error Information”.
Voice & fax ---, Ready
The communication status for CS (Voice, Fax,
UDI, RDI) will be displayed.
Note) “- - -”: Communication unavailable
Data connection
---, Connected,
Not connected
The PS communication status will be displayed.
Note) “- - -”: Communication unavailable
Standard data ---, x [kBytes] Packet data volume will be displayed.
Communication
status
Streaming data
0:
x (8kbps), x(16kbps)
x (32 kbps), x (64 kbps),
x (128 kbps), x (256 kbps)
The number of sessions currently connected will
be displayed.
HPA xx [degree] The temperature detected for the HPA Module
IF xx [degree] The temperature detected for the IF board
Main
Cont’d
Status
monitor
Temperature info
Modem xx [degree] The temperature detected for the MODEM board
To Next Page
