12.3 BDE Software Updating Tool
12-21
3. When Updating the Incoming Indicator
The updating process will be executed while the data is being forwarded. The displays
upon the Incoming indicator such as [ACK] LED will not change.
While the updating procedure is in process, no buzzer sound will be made even if you
press the button on the panel. When you are updating all software for the Incoming
indicator, it will take approx. 3 minutes to complete.
Note)
When the updating process is completed, the Incoming indicator is rebooted
automatically. After having rebooted the system, confirm that the ACK button is
lighted for 3 seconds, and that the system operates in a normal manner.
Reference) What ( ) in the device line means;
For example, in the case of device: HUBCPU (00:0D:1D:03:41:52, 192. 168.1.1);
x “00:0D:1D:03:41:52” is the MAC address, and
x “192. 168.1.1” is the HUB CPU IP address.
If the Incoming indicator is detected,
the IP address for the Incoming
indicator will be dis
indicator is detected,
the IP address for the Incoming
indicator will be displayed.
“Done” will be displayed when the writing
process has completed successfully.
To Next Page
