10.1 Overview
10-2
10.1.2 The Structure of the Web MMI
If you click the menu for the “Navigation bar area”, the menu will be displayed in the
“Menu display area.”
The menu selected in the “Menu display area” will be reflected upon the contents
display area.
1. User Authentication Area: Admin login
The contents of the Navigation bar menu will vary between the Users' mode,
Administrator's mode, and Service mode.
In order to enter the Administrator's mode or Service mode, click the box [admin login]
in the user authentication area, and enter the Username and Password required for
entering each mode.
Mode User name Password Navigation bar area menu
Users' mode Main, SMS, Contacts, SIM
Administrator's
mode
Admin 01234567
Main, SMS, Contacts, SIM,
Setting, Device, Log, Selftest
Service mode Service fb5963
Main, SMS, Contacts, SIM,
Setting, Device, Log, Selftest, Service
Contents display area
User authentication
Signal strength
display
Model name
display
Own vessel
position display
Date/time display
Alarm display
Menu display area
Navigation bar area
