Furuno FELCOM 250 Service Manual

   
3.1 Web MMI

3-17
Navigation
Bar Menu
Menu Contents area Items-1 Items-2 Note
LAN port1 [W] LAN port2 [W] LAN port3 [W]
PoE feeding
LAN port4 [W]
The PoE feed status will be displayed.
Tx ATT [dB] Rx ATT [dB]
Gain & ATT information
Demodulator gain [dB]
Displayed based on Antenna cable Calibration
Tx PLL frequency [MHz] Tx PLL status Rx PLL frequency [MHz]
BDE
PLL information
Rx PLL status
The status of the PLL circuit for the IF board will be displayed.
. Analog port 1 . Analog port 2 . Analog port 3
Extension (Only analog phone)
. Analog port 4
The setting for the Echo canceller
. Voice
Echo canceller
Outside call
. FAX
The setting for the Echo canceller for the external calls
. ADE . ATB . HPA
Service
Restart
. BDE
To be restarted individually
