GE Dash 2500 User Manual

2042480-001 C Dash 2500 Patient Monitor 10-7
RESP: Specifications
Specifications
Specifications
ECG-Derived Respiration Rate
Leads available I or II
Range 6 to 120 breaths/min (adult/pediatric)
6 to 180 breaths/min (neonate)
Accuracy ± 2 breaths/min or ± 3%
of reading; whichever is greater
Resolution 1 breath/min
Base Impedance 100 to 2000 Ω
Detection Sensitivity 0.2 Ω @ 30 breath/min with 500 Ω baseline impedance
Excitation Frequency 65.5 kHz
Amplitude
< 300 µA rms

GE Dash 2500 Specifications

General

Brand	GE
Model	Dash 2500
Category	Medical Equipment
Language	English
