2042480-001 C Dash 2500 Patient Monitor 12-11
NELLCOR® OXIMAX® SpO2: Specifications
Specifications
Specifications
Measurement Range
SpO
2
1 to 100%
Pulse Rate 20 to 250 bpm
Perfusion Range 0.03 to 20%
Accuracy
Saturation
Adult* 70 to 100% ±2 digits
Neonate* 70 to 100% ±3 digits
Low Perfusion** 70 to 100% ±2 digits
Pulse Rate
Adult and Neonate 20 to 250 bpm ±3 digits
Low Perfusion** 20 to 250 bpm ±3 digits
*Adult specifications are shown for OxiMax
®
MAX-A and MAX-N sensors with the N-600. Saturation accuracy will vary by sensor type.
**Applicability: OxiMax
®
MAX-A, MAX-AL, MAX-P, MAX-I, and MAX-N sensors.
Specifications: NELLCOR
®
OXIMAX
®
Sensor Accuracy
NOTE: All NELLCOR
®
OXIMAX
®
sensors must be used with the NELL1 GE cable; the SCP-10 cable. RS-10 and
Oxisensor
®
II sensors are not compatible with the Dash 2500 Patient Monitor.
Sensor Model
SpO
2
Range
70% - 100%
O
XIMAX
®
MAX-A, MAX-AL ±2 digits
MAX-N
(Adult)
±2 digits
MAX-N
†
(Neonate)
±3 digits
MAX-P ±2 digits
MAX-I ±2 digits
MAX-FAST ±2 digits
SC-A (Adult) ±2 digits
SC-PR (Neonate) ±3 digits
MAX-R
‡
±3.5 digits
