2042480-001 C Dash 2500 Patient Monitor 13-3
MASIMO SET® SpO2: Description
Description
The SpO
2
parameter in the Dash 2500 Patient Monitor is available in two
different leading technologies: NELLCOR
®
and MASIMO SET
®
. The SpO
2
technology logo will be on the side of the Monitor next to the SpO
2
connector.
This section refers to MASIMO SET
®
SpO
2
technology.
Functional oxygen saturation (SpO
2
) of arterial blood is monitored in the Dash
2500 Patient Monitor by a pulse oximetry parameter that provides continuous,
noninvasive measurements of SpO
2
and can provide displays of pulse rate, a
plethysmographic waveform, and a signal strength bar. The signal strength bar
is an indication of the confidence associated with the saturation measurement
and timing of the pulse. To begin SpO
2
monitoring, plug the sensor cable into the
SpO
2
port, place the SpO
2
sensor on the patient's finger, and monitoring begins
automatically.
Functional SpO
2
is the ratio of oxygenated hemoglobin to hemoglobin that is
capable of transporting oxygen. This ratio, expressed as a percentage, is shown
in the SpO
2
field of the screen and is updated with each heart beat. The
percentage of SpO
2
is also indicated by a pulse tone that is activated by the
Adjust QRS volume option in the HR/Pulse menu. The pitch frequency of the
tone is proportional to the oxygen saturation value: highest at 100% saturation
and lower as the level of saturation falls.
Pulse Rate derived from SpO
2
appears under the following conditions:
 View SpO2 PR? option is set to yes:
When pulse rate (PR) is derived from SpO
2
, the value appears in the SpO
2
vital signs field.
NOTE: Unless PR is the source for the HR/Pulse, it is only trended when the
View SpO2 PR? option is set to yes.
 View SpO2 PR? option is set to no:
PR will not appear in the SpO
2
vital signs field, but SpO
2
is still a valid source
for the HR/Pulse.
 When SpO
2
is the source for the HR/Pulse:
Pulse rate derived from SpO
2
appears only in the HR vital signs field (dashes
appear for PR in the SpO
2
vital signs field).
The SpO
2
parameter has audible and visible alarms to let you know when the
SpO
2
levels are outside the alarm limits. If the View SpO2 PR? option is set to yes,
audible and visible alarms for the pulse rate (derived from SpO
2
) are activated.
The alarm limits for PR are the same as those for HR/Pulse.
*MASIMO SET
®
is a trademark of MASIMO Corporation. Possession or purchase of this device does not convey any express or implied license to
use the device with replacement parts which would, alone, or in combination with this device, fall within the scope of one or more of the patents
relating to the device.
®
