2042480-001 C Dash 2500 Patient Monitor 6-9
Trends: View Patient Trends Menu: Graphs
Trends of parameters not continuously updated are displayed in the time
interval when the measurement was taken (i.e., NIBP). These time intervals will
also include trends for other vital signs.
View vitals for
This menu option is available when the Display as option is set to graphs. It lets
you choose the span of time to view the mini trends window. You can choose 50
min, 100 min, 2.5 h, 5 h, 10 h, 15 h, 20 h, or 24 h intervals.(Dashes are unavailable
and cannot be chosen.)
Config settings
This option allows you to view, but not change, the various configuration
options. To change any config option, you must go into the password-protected
Configuration Mode. Refer to the Dash 2500 Patient Monitor Service Manual
(PN 2042481-001) for more information.
View Patient Trends Menu: Graphs
print chosen graphs
This option lets you print chosen graphs currently displayed on the trends
screen. (Go to Choose graphs option to make selection.) If no graphs have been
chosen and this option is selected, the top two waveforms are printed. It is
available when the printer is not busy, trended patient data other than an admit
mark is displayed, and the Display as option is set to graphs.
