System Measurements
What You’ll
This chapter describes how to make cable TV measurements using the system
Find in This
measurements mode of operation (SYSTEM MEAS ). This chapter contains the
Chapter
following sections:
l making system measurements
l making timed system measurements
0 creating a test plan
l editing the current test plan
l clearing the current test plan
0 cataloging analyzer memory
l recalling a test plan from a RAM card
l recalling test data from the RAM card
l cataloging a RAM card
l formatting a RAM card
l deleting all the Iiles from a RAM card
l deleting individual Eles from a RAM card
The following tests can be performed in SYSTEM
MEAS mode:
0 visual/aural carrier levels
0 visual/aural carrier frequencies
l depth of modulation
. humt
l csot *
0 carrier-to-noise ratio
l DG, DP, CLDIt *
l in-channel frequency responset *
l FM deviation
If a test fails in the SYSTEM
MEAS mode, confirm the failure using
CHANNEL MEAS mode. This may involve disabling carriers or modulation
according to FCC rules. Relative measurements showing cable TV equipment
contributions may also be helpful in meeting FCC requirements.
t Cannot perform on scrambled channels.
* Option 107 required.
