Channel Measurements
Making Channel Measurements
12. /tp 23 23 NO”
23. 1993
REF 119 5 mV
AT IO dB
WA SB
SC TC
CORR
CENTER 69.000 MHz
#RES BW 300 ktiz
#VBW 3 MHZ
SPAN 0 HZ
RSWP 80 psec
SELECT
LINE
FIELD
ODD EE
AUTO SIG
SEARCH
Select
Test Slg
CONTINUE
Figure 2-24. NTC 7 Composite Test Signal
NOTE
These measurements cannot be performed without a test signal containing a modulated staircase. The
5-step riser start and stop timing can affect measurement results if the timing is different from the
defined standard.
