View Co-Channel
Test
Description
The view co-channel test measures the frequency and level of two signals
within the same channel and within pickup distance of each other. If the
co-channel level is high enough, the TV receiver will display two separate
signals on one channel.
Note that this test is only available in Channel mode.
83129:56
JAN 12. 1993
+7
CHhNNEL
m
(ST01
REF 22.7
dBmU
ATTEN
10
dB
MKR
0.
lG.00
kHz
m
-37.73
dB
MARKER
A
10.00 kHz
A
I-37.79 dB
/
\
: :
:
MRIN
MENU
CENTER 67.23675 NHz SPAN 58.88 kHZ
RES BW 1.B kHz
#'JEW
18
Hz SWP 15.8 set
Figure E-20. View Co-Channel
8-47
