System Measurements Menu Map and Softkey Descriptions
System Measurements
Softkey
Function Descriptions
Recalling a test plan
from plan 1
Recalling a test plan overwrites the current test plan. If you do not want the
current test plan to be overwritten, save the current test plan before recalling
a test plan. When you recall the a test plan from test plan 1, it is recalled
from trace register 6.
The location code, the temperature, the selection of CTB testing, and the
setting for an external pad (EXT PAD YES NO
)
are not recalled with the test
plan. Before initiating testing with a recalled test plan, you may want to do
the following:
l Enter the location code.
l Enter the temperature reading.
l Change the setting of the CTB testing (in Setup menu).
l Change the setting of the external pad compensation (in Setup menu).
Press CABLE TV ANALYZER, SYSTEM
MEAS,
More 1 of 2,
Create TstPlan, Save TstPlan, then SAVE TO INT MEM to
access PLAN 1 . Or, press CABLE TV ANALYZER , SYSTEM
MEAS
,
Recall TstPlan , RECALL FRM I$T to access PLAN 1
See Also “Step 3. Save the current test plan in internal memory” in Chapter 3.
“Step 5. Recall a test plan” in Chapter 3.
PLAN
2
Description
Allows you to select test plan 2 as the test plan number for either saving the
current test plan or recalling a previously saved test plan.
The operation of PLAN 2 is identical to PLAN 1 except that the test plan is
stored in and recalled from trace register 7.
6-24
