System Measurements Menu Map and Softkey Descriptions
System Measurements
Softkey
Function Descriptions
RECALL
FRM
INT
Description
Allows you to recall a previously saved test plan (from plans 1 through 5)
from analyzer memory.
Recalling a test plan overwrites the current test plan. If you do not want the
current test plan to be overwritten, save the current test plan before recalling
a new one. See “Step 3. Save the current test plan in internal memory” in
Chapter 3 for more information.
The test plans are saved in trace registers 6 through 10.
The channel numbers, tests, scrambling status, channel tuning conEguration,
quiet line number, frequency response line number, test signal line number,
and Eeld selection are saved in the test plan.
The location code, the temperature, the selection of CTB testing, and the
setting for an external pad (EXT PAD YES NO
)
are not stored with the test
plan but are stored in nonvolatile analyzer memory and are retained until
changed.
Before initiating testing with a recalled test plan, you may want to do the
following:
l Enter the location code.
l Enter the temperature reading.
l Change the setting of the external pad function (in Setup menu).
Pressing CABLE TV ANALYZER, SYSTEM
MEAS,
Recall
TstPlan
accesses
RECALL FRM INT
See Also
“Step 5. Recall a test plan” in Chapter 3.
6-28
