HP 8591C User Manual

I
-
TV Receiver, Setup, and AUX CTRL Menu Maps and Softkey Descriptions
Softkey Descriptions
The default value for the channel tuning configuration is the standard (STD)
channel format. In addition, the
USR CN 0 CNTR FRQ and USR CH 0 SPAN
softkeys allow you to define the center frequency and span for a user defined
channel. This channel is then accessed by selecting channel 0 (zero).
The default settings are for channel 2 (STD). These settings are stored in
non-volatile analyzer memory. This means that the analyzer retains the
selections, even when power is turned off, until a new selection is made.
Press
CABLE TV ANALYZER , Setup , to access Channel Tuning
See Also “Step 1. Configure the test system” in Chapter 2.
CSO FREQ OFFSET andCTB FREQ OFFSET
Description
Allows you to specify the location above or below a visual carrier to measure
system CSO and system CTB. The defaults are channel 4, CTB 6 MHz above
the visual carrier, and CSO 4.75 MHz above the visual carrier.
Simply press CSO FREQ OFFSET (CSO) and/or
C’I’B FREQ DFFSET (CTB),
enter a positive frequency to measure above the visual carrier or a negative
frequency to measure below the visual carrier, then press
CENTER_).
Press CABLE TV ANALYZER, Setup , System Beats to access
CSO
FREQ OFFSET and CTB FREQ OFFSET.
See Also
“Step 1. Configure the test system” in Chapter 3.
7-9
