System Measurements
Making System Measurements
Step 1. Configure the test system
The Setup menu is used to set up channel tuning, a user deEned channel,
an external preampliEer, and an external matching pad (50
61
analyzers only).
The information is stored in nonvolatile analyzer memory. This means that
the analyzer retains the information, even when power is turned off, until
you access the Setup menu again and change it.
l.
If the Setup softkey is displayed, press it now. Otherwise, press
(MODE)
CABLE
TV
ANALYZER
Setup.
2.
Press Channel Tuning, then press STD AIR HRC IRC T until the
desired format is underlined.
The tune conEguration menu allows you to select channel format:
l STD-Standard Cable
l AIR-Broadcast Channel
l HRC-HRC Cable
l IRC-IRC Cable
l T-Upstream Channels
3. Press Prev Menu to return to the main menu.
3-4
