Recalling a Test Plan from a RAM Card
1. If RECALL FRM CRD is not displayed, press
[MODE],
CABLE
TW
ANALYZER, Recall
TstPlan.
2.
Press RECALL FRM CRD .
3. Press the
softkey
with the plan number you want to recall. For example,
press PLAN 1 to recall the test plan in plan number 1.
4.
Press DONE.
3-34
