I
-
TV Receiver, Setup, and AUX CTRL Menu Maps and
Softkey
Descriptions
Softkey
Descriptions
In spectrum analyzer memory, the setting of the external pad function entry
is not stored with the current test plan in plans 1 through 5. The setting of
the external pad function is stored in nonvolatile spectrum analyzer memory,
however. Storing the setting in nonvolatile memory means that once the
external pad function is set to YES, it will remain set to YES until you change
the setting or delete the HP 85721A personality program from analyzer
memory.
Press CABLE TV ANALYZER , Setup, Analyzer Input to access
EXT PAD YES NO
See Also
“Step 2. Connect the signal to the analyzer” in Chapter 2.
HRC
Description
Allows you to select the harmonically related carriers (HRC) tune
configuration. HRC is the channel tuning configuration in which the
frequency of each video carrier is a multiple of 6 MHz.
If you do not select a channel tuning configuration, the default configuration
is the standard (STD) conEguration. The choices for the channel tuning
configuration are: standard (STD), off-the-air (AIR), incrementally related
carriers (IRC), harmonically related carriers (HRC), and T format.
The analyzer retains the channel tuning configuration selection, even when
power is turned off, until a new selection is made.
Press CABLE
TV
ANALYZER , Setup, Channel Tuning to access HRC
See Also
“Step 1. Configure the test system” in Chapter 3.
7-12
