DETAILED CONTROLS AND GAUGES OPERATION
3-34
HOT AND COOL BOX 3
This is on the right side at the rear of the operator's seat. It is
interconnected with the air conditioner: it stays warm when the
heating is used, and stays cool when the cooling is used.
MAGAZINE BOX 3
(The cup holder is provided separately at the front of the magazine box.)
This is on the left side of the operator's seat.
Keep the Operation and Maintenance Manual in this box so
that it can be taken out and read whenever necessary.
ASHTRAY 3
This is under the machine monitor at the front right of the oper-
ator's compartment.
Always make sure that you extinguish your cigarette, then put it
in the ashtray and close the lid.
