OPERATION DETAILED CONTROLS AND GAUGES
3-5
Basic Check Monitors 3
CAUTION
These monitors DO NOT ensure that the machine is in good condition. When performing checks before
starting (daily checks), do not simply rely on the monitors. Always dismount the machine and check each
item directly.
This displays the basic items that should be checked before starting the engine.
If there is any abnormality, the appropriate monitor lamp will flash.
Engine Oil Level Monitor
This monitor (1) lights up to warn the operator that the oil level
in the engine oil pan has gone down.
If the monitor lamp flashes, check the oil level in the engine oil
pan, and add oil.
A (1) Engine oil temperature monitor A (2) Engine oil change monitor (only if equipped)
To Next Page
