OPERATION DETAILED CONTROLS AND GAUGES
3-51
FUSIBLE LINK 3
If the starting motor does not work when the starting switch is
turned ON, the wire type fusible link (1) (2 places) is probably
broken, so open the battery box cover on the right side of the
machine, then check and replace.
REMARK
A fusible link refers to the large-sized fuse wiring installed in
the high current flow portion of the circuit to protect electrical
components and wiring from burning, in the same way as an
ordinary fuse.
CONTROLLERS 3
controller installed.
NOTICE
q Be careful not to get water, mud, or juice on the con-
troller. This will cause failure.
q If any abnormality occurs in the controller, do not dis-
assemble it yourself. Contact your Komatsu distribu-
tor for repairs.
TOOL BOX 3
This is used for keeping the tools.
GREASE GUN HOLDER 3
This is inside the battery room door on the left side of the
machine.
When not using the grease gun, fit it in this holder.
