OPERATION COLD WEATHER OPERATION
3-119
AFTER DAILY WORK COMPLETION 3
WARNING
Performing idle-running of the tracks is dangerous, so stay well away from the tracks.
To prevent mud, water, or the undercarriage from freezing and making it impossible for the machine to move on
the following morning, always observe the following precautions.
q Remove all the mud and water from the machine body. In particular, wipe the hydraulic cylinder rod clean to
prevent damage to the seal caused by mud or dirt on the rod surface getting inside the seal together with
drops of water.
q Park the machine on hard, dry ground.
If this is impossible, park the machine on wooden boards.
The boards help protect the tracks from being frozen in soil so the machine can move next morning.
q Open the drain valve and drain any water collected in the fuel system to prevent it from freezing.
q Fill the fuel tank to the full in order to prevent moisture from forming dew in the tank room, as the ambient tem-
perature goes down.
q After operation in water or mud, remove water from undercarriage as described below to extend undercarriage
service life.
1. Swing 90° with engine at low idling and bring the work
equipment to the side of the track.
2. Jack up the machine until the track is raised slightly from
the ground. Rotate the track under no load. Repeat this
procedure on both the left and right sides.
AFTER COLD WEATHER SEASON 3
When season changes and the weather becomes warmer, do as follows.
q Replace the fuel and oil for all parts with oil of the viscosity specified.
For details, see “LUBRICANTS, FUEL AND COOLANT SPECIFICATIONS (4-10)“.
q If for any reason permanent antifreeze cannot be used, and an ethylene glycol base antifreeze (winter, one
season type) is used instead, or if no antifreeze is used, drain the cooling system completely, then clean out
the inside of the cooling system thoroughly, and fill with fresh coolant.
