MAINTENANCE MAINTENANCE PROCEDURE
4-43
BLEEDING AIR FROM HYDRAULIC SYSTEM 4
For details, see “STARTING ENGINE (3-72)“. If it is necessary to refer to the items for starting the engine, moving
the machine off, steering, or stopping, see the OPERATION section.
1. Bleeding air from pump
2. Loosen air bleed plug (1) and check that oil oozes out from
the air bleeder.
3. If the oil does not ooze out, remove the drain hose from the
hydraulic pump case and fill the pump case completely
with hydraulic oil through drain port (2).
Hold the removed hose firmly, keeping the mouthpiece
higher than the oil level in the hydraulic tank so that oil will
not spill out of the hose.
4. After completing the air bleed operation, tighten air bleed
plug (1) and install the drain hose.
NOTICE
If the drain hose is installed first, oil will spurt out from plug hole (1).
If the pump is operated without filling the pump case with hydraulic oil, abnormal heat will be generated
and this may cause an unexpected damage to the pump.
5. Starting engine
Start the engine, referring to “STARTING ENGINE (3-72)“.
Run the engine at low idling for 10 minutes after starting, then start operations.
6. Bleeding air from cylinders
7. Run the engine at low idling, and extend and retract each
cylinder 4 to 5 times, taking care so that a cylinder may not
be brought up to its stroke end. (Stop the cylinder approx.
100 mm short of its stroke end)
8. Next, operate each cylinder 3 to 4 times to the end of its
stroke.
9. Finally, operate each cylinder 4 to 5 times to the end of its
stroke to completely remove the air.
NOTICE
If the engine is run at high speed immediately after startup or a cylinder is pushed up to its stroke end, air
taken inside the cylinder may cause damage to the piston packing.
