SAFETY MACHINE OPERATION SAFETY
2-32
TRANSPORTATION 2
The machine can be divided into parts for transportation, so when transportating the machine, please contact your
Komatsu distributor to have the work carried out.
LOADING AND UNLOADING
When loading or unloading the machine, mistaken operation
may bring the hazard of the machine tipping over or falling, so
particular care is necessary. Always do as follows.
q Perform loading and unloading on firm, level ground only.
Maintain a safe distance from the edge of the road or cliff.
q Never use the work equipment to load or unload the
machine. There is danger that the machine may fall or tip
over.
q Always use ramps of adequate strength. Be sure that the
ramps are wide, long, and thick enough to provide a safe
loading slope. Take suitable steps to prevent the ramps
from moving out of position or coming off.
q Be sure the ramp surface is clean and free of grease, oil, ice and loose materials. Remove dirt from machine-
tracks. On a rainy day, in particular, be extremely careful since the ramp surface is slippery.
q Turn the auto-decelerator switch OFF (auto-deceleration function released).
q Run the engine at low speed and travel slowly.
q When on the ramps, do not touch any other parts.
q Never correct your steering on the ramps. If necessary, drive off the ramps, correct the direction, then enter
the ramps again.
q The center of gravity of the machine will chenge suddenly at the joint between the ramps and the track or
trailer, and there is danger of the machine losing its balance. Travel slowly over this point.
q When loading or unloading to an embankment or platform, make sure that it has suitable width, strength, and
grade.
q When swinging the upper structure on the trailer, the trailer is unstable, so pull in the work equipment and
swing slowly. And turn swing lock switch ON to apply swing lock after loading machine.
q For machines equipped with a cab, always lock the door after boarding the machine. If this is not done, the
door may suddenly open during transportation.
Refer to “TRANSPORTATION (3-107)“.
SHIPPING THE MACHINE
When shipping the machine on a trailer, do as follows.
q The weight, transportation height, and overall length of the machine differ according to the work equipment, so
be sure to confirm the dimensions.
q When passing over bridges or structures on private land, check first that the structure is strong enough to sup-
port the weight of the machine. When traveling on public roads, check first with the relevant authorities and fol-
low their instructions.
q For details of the shipping procedure, see “TRANSPORTATION (3-107)“ in the OPERATION section.
Blocks
Block
Distance
between ramps
Max. 15°
Ramp
