MAINTENANCE MAINTENANCE PROCEDURE
4-67
EVERY 2000 HOURS MAINTENANCE 4
Carry out the periodic maintenance work of every 100, 250, 500 and 1000 hours of operation at the same time.
CHECK PTO GEAR CASE, ADD OIL 4
WARNING
Engine parts and oil are at high temperature immediately after the engine is stopped, and will cause seri-
ous burns. Wait for the temperature to cool down before starting the operation.
1. Swing the upper structure so that the PTO gear case is in
the middle between the left and right tracks.
Stop the engine and set the safety lock lever to the LOCK
position.
2. Remove the cover under the right side of the machine.
3. Remove plug (G) and check that the oil level is near the
bottom edge of the plug hole. If the oil level is low, remove
plug (F) and add oil through the hole of plug (F) until the oil
is up to the bottom edge of the hole of plug (G).
4. Install plugs (G) and (F).
5. Install the cover.
