200 Chapter 22: Events (Automation)
PRO6 Live Audio System
Owner’s Manual
Connecting up the MIDI/GPIO equipment
The PRO6 has a set of MIDI sockets on the rear panel for connecting MIDI equipment
(see “MIDI section” on page 246). There is also an equivalent set on the rear panel of
the DL351 Modular I/O.
GPIO connections for the PRO6 are via the rear panel of the DL351 Modular I/O. The
PRO6 Control Centre doesn’t have any GPIO connections.
About the Edit Event window
You can edit the parameters of an event in the Edit Event window and even change its
name.
Item Description
1 Disable Event tick box, for choosing whether the event is missed out
(skipped) during a rehearsal.
2 TEST EVENT button, for executing the selected outgoing MIDI or GPIO
event using the current event parameters. (Outgoing events only.)
3 When... section for selecting the parameters that trigger the event.
Displays either one or three drop-down lists, depending on the whether the
event is selected as Outgoing or Incoming, respectively.
4 Time Offset section, for setting the period of time that the event happens
after it has been triggered. Zero = no offset.
5 Then do this... section, for choosing the type of event that you want.
6 Event Parameters section (see the “Programming events” on page 201).
7 CLOSE button, for closing the Edit Event window.
8 Incoming/outgoing selection section, for selecting whether the event is
triggered on the XL8 or on an external device.
