418 Appendix K: Parameters Affected By Scope
XL8 Live Performance System
Owner’s Manual
GEQ rack
Each scope screen has up to five eight-slot racks in the Graphic EQs section, which can
contain a maximum of 36 GEQs (as shown below). The number of racks and GEQs are
configuration dependent.
Note: A rack slot in the Graphic EQs section in equivalent to a the All scope area.
Patching
The following diagram details the scoped patching parameters of the GEQs, which are
shown on the Graphic GEQs screen (below).
ABC D E F G H
Item Parameter
1 Bus assignment/type N/A No N/A N/A N/A N/A N/A N/A
