Field Replaceable Unit 8-19
8.2.5 Main Unit Assembly (E0)
No. Order Number Part Name Qty. Remark
E1
043-005615-00
screw cover for protective cover A
1
E2
043-005916-00
screw cover D for top cover
1
E3
043-005613-00
screw cover for back cover B
1
E1
E3
E7
E2
E4
E5
E6
E8
E9
E10
E13
E14
E15
E11
E12
