8-32 Field Replaceable Unit
8.2.9 Fusion Imaging Assembly (I0)
No.
Order Number
Part Name
Qty.
Remark
I1
115-034852-00
cantilever assembly
1
I2 115-040847-00 Connect Base Assembly 1
I3 043-006786-00 Base Cover(Transport) 1
I4 801-1112-00003-00 UMT-160 Trolley Caster and Spanner(FRU) 1
I5
I6
I7
I4
I3
I2
I1
