Mindray Eagus R9 User Manual

Troubleshooting of Regular Malfunctions 13-3
13.2 System Cannot Start
13.2.1 Related Modules or Boards
No. Description Remarks
1
PC carrier board assembly
/
2 CPU module assembly /
3
SSD card
/
4
Battery assembly
/
13.2.2 Key Points Supporting Troubleshooting
No.
Key Points Supporting Troubleshooting
Remarks
1 The display and progress status when starting the system /
2
Alarm and prompts when starting the system
/
3 Backlight status on the control panel /
4 Display indicator /
5
Battery indicator
13.2.3 Troubleshooting—The System Cannot Start
No. Fault Description Cause Analysis Solution
1
The backlight on the control
panel is normal; the display
is blank; no signal appears.
System powers on normally.
Enter BIOS self-checking but
BIOS screen does not appear.
CPU module failure.
Replace CPU module
2 BIOS start-up graphics is
normally displayed, but it
does not proceed.
CPU module failure Replace CPU module
3 “OPERATING SYSTEM
NOT FOUND” appears.
Loading operation fails. Hard
disk and root directory of SSD
disk in operation system are
corrupted.
Restore the operating
system. If fails, replace the
SSD disk.
4 BIOS start-up graphics
appears, and then becomes
black.
Unable to load the system.
The system directory of SSD
disk may be corrupted.
Restore the operating
system. If fails, replace SSD
disk.
5
System Doppler start-up
graphics appears but it
does not proceed.
Fail to load the system
software. SSD disk or system
software in SSD disk may be
corrupted.
Restore the operating
system. If fails, replace the
SSD disk.
