11-8 System Diagnosis and Support
Monitor:[XXX] abnormal alert!
assembly.
N/A
"Date" "Time" E010: System
Monitor: Motor driving board alert!
Motor control board and motor
driving board communication
error!
Replace the electrical control panel or
electrical drive board.
N/A
"Date" "Time" E011: System
Monitor: Motor control board alert!
Motor control board and motor
driving board communication
error!
Replace the electrical control panel or
electrical drive board.
"Errocode"
[XXX]
button; it
may be
blocked.
"Date" "Time" "Errocode": System
Monitor: Key stuck alert! [YYY] key
is stuck!
Check whether it can be solved
manually. Replace the upper cover of
the keyboard or encoder.
11.3.8 Error Code List
The error code is shown below:
Error
code
The place where
the test happens
FRU where the test happens
V001 A12_ACDC
DC box assembly
Source: AC power supply assembly
Load: DC box assembly, PHV box assembly, PC carrier
board assembly, GPU module assembly;
Engine board: TR board, monitor material package, touch
screen assembly, upper cover of the keyboard, coupling gel
heating cup.
V002 DP5V
DC box assembly
Source： DC box assembly
Load: IO assembly, PC carrier board assembly, DVD
assembly, hard disk assembly, touch screen assembly, USB
interface
V003 AP6V
DC box assembly
Reserved
V004 AP5V7
DC box assembly
Source: DC box assembly
Load: probe board assembly, engine board, TR board
V005 N12V
DC box assembly
Source: DC box assembly
Load: TR board
V006 N5V7
DC box assembly
Source: DC box assembly
Load: PC carrier board assembly, TR board
V007 AP2V9
DC box assembly
Source: DC box assembly
Load: TR board, IO assembly
