18Service Manual – SC5000 03 - General Information
Rear LH View
21 Tie Down Location (2 rear) 31 Squeegee Mount Thumb Nuts
23 Control Panel 32 Squeegee Caster Lock Knob
24 Recovery Tank Cover 33 Squeegee Assembly
25 Recovery Tank Shutoff Float 34 Hopper (Cylindrical only)
26 Vacuum Motor Filter Housing 35 Scrub Deck
27 Debris Catch Tray 36 Solution Filter
28 Recovery Tank Drain Hose 37 Solution Shutoff Valve
29 Recovery Hose 38 Solution Solenoid Valve (on scrub deck)
30 Squeegee Tilt Adjust Knob 40 Brake Pedal
