38Service Manual – SC5000 04 - Control System
System Menu
The system menu displays the rmware revision number and
the serial number of the control board. It also provides access for
updating the rmware, and checking the impact log.
Impact Log
If an impact event occurs and the machine has been set up for the
“lock out” option, a pad lock symbol is shown to the operator and
scrubbing functions are inhibited. The machine can still be driven., but the machine must be powered on
using a supervisor key to “reset” the lock out and restore scrubbing functions.
The impact log will display a list of impact events with an impact value of acceleration in 1/1000 G’s
(Gravity). If an individual impact event is viewed, all three axis of acceleration are displayed.
System
MMC Firmware
Back
Select
UI Firmware
Install MMC Firmware
Install UI Firmware
99.99.99.9
15.14.0009
To Next Page
Loading...
