34Service Manual – SC5000 04 - Control System
A4 Drive Controller
The Drive Controller menu provides status information about the drive motor and the drive controller itself.
A brief summary of each listing is described below.
Speed (mph/kph): This displays the actual speed of the machine.
Throttle %: This displays the throttle position as percent of
maximum position.
Throttle Voltage: This displays the wiper voltage from the throttle
potentiometer.
Motor Current: This displays the net amperage to the drive motor.
RPM: This displays the output rpm of the wheel motor.
Motor Temperature: This represents the internal temperature (˚C)
of the wheel motor. The motor has an internal temperature sensor
and reports this value to the Drive Controller.
A4 Voltage: This represents the battery voltage present at the drive
controller.
A4 Temperature: This represents the internal temperature (˚C) of the drive controller itself.
A4 Drive Controller
Speed (mph/kph)
Back
Scroll
Throttle %
Throttle V
Motor Current (A)
0.0
0
1.0
0.0
A4 Drive Controller
Motor RPM
Back
Scroll
Motor Temperature (C)
A4 Voltage
A4 Temperature (C)
0
14
32.3
14
To Next Page
