30Service Manual – SC5000 04 - Control System
Programming Menu Outline
B1 Battery
Pack State of Charge
Pack State of Health
Pack Voltage (V)
Pack Amperage (A)
Operational Modules
E
Active Faults
E
Fault History
E
Module Capacities
E
Min/Max Cell Temps
E
Module Charge Cycles
E
Module Discharge Cycles
E
Accumulated Charge (KAh)
E
Low/Normal/Hi Temp Chgs
E
Module Voltages
E
Module Amperages
Service Menu
A1 Main Controller
A2 Power Module 1
A4 Drive Controller
Output Test
Panel Test


= Service-Only Access
A2 Power Module
Mx PWM %Req
Mx PWM %Out
Mx Amps
Where:
M1 = Front Cyl Motor
or Right Disk Motor
M2 = Rear Cyl Motor
or Left Disk Motor
M4 = Vacuum Motor 1
M5 = Vacuum Motor 2
M6 = Squeegee Actuator
M7 = Deck Actuator
M8 = Option Pump
B+ (V)
Tempurature ºC
Main Menu
Hours
Faults
Keys
Service
System
Options
Configuration
On Time
Drive Time
Scrub Time
Recovery Time
Hours Menu
Brand
Deck
Side Sweep
Ecoflex
Option Pump
Battery
Charger
Vacuum
Beacon
TrackClean
Configuration

Active Faults
Fault History
Clear History

Faults Menu
Read Key
Key List
Keys Menu
System Menu
MMC Firmware
UI Firmware
CSP190-Comm F/W
CSP190-Motor F/W
MMC S/N
UI S/N
Install MMC F/W
Install UI Firmware
Impact Log
Scrub Startup
Scrub Max
Burst of Power
Solution (Mode)
Solution In Rev
Lock Detergent
Neutral Delay
Forward Speed Max
Lock Speed Limit
Beacon (Headlights)
Vac Off Delay
Language
Floor (Type)
Options Menu
Inactive Time (min)
Impact Detect
Impact Level
A4 Drive Controller
Speed (mph/kph)
Throttle %
Throttle V
Motor Current (A)
Motor RPM
Motor Temperature
Voltage (V)
Temperature (C)
A1 Main Controller
J1-16 B+ (V)
J1-15 KSI Relay
J1-12 KSI
J2-7 E-Stop
J2-5 Seat Switch
J2-6 OBC Interlock
J1-11 Horn
J1-10 Backup Alarm
J1-8 Beacon
J2-3 Solution Level
J2-4 Sweep SW
M24 Detergent Pump
ACCEL-X (mG)
ACCEL-y (mG)
ACCEL-z (mG)
J1-14 Solution Sol
Output Test
J1-10 Backup Alarm
J1-8 Beacon
J1-11 Horn
J1-14 Solution Sol
M9 Det Pump
M6 Squeegee
M7 Deck
M8 Option Pump
M5 Vacuum 2
M4 Vacuum 1
M3 Side Sweep
M1 Front Cyl Motor
or Right Disk Motor
M2 Rear Cyl Motor
or Left Disk Motor
Note: Some menu items are visible
only when the option is
installed
While Charging
Charger Menu
Battery SOC
Battery Voltage
AC Line Voltage
Charger Temp (C)
Fault
Fault History
Current Cycle
Extended Status
Cumulative Counts
Firmware & Algos



