Nilfisk-Advance Advance SC5000 Service Manual

185Service Manual – SC5000 34 - Scrub System, Disc
Brush Motor Brushes
1. Remove the Scrub Deck described on page
183.
2. Remove the 3 screws (A) that secure the
splash cover (B) to the top of the motor, and
remove the cover.
3. Make a witness mark (C) on the edge of
the motor end bell to mark the rotational
position of the end bell with respect to the
motor housing.
4. Remove the two long bolts (D) that secure
the motor end bell to the motor, and remove
the end bell. Take care to not lose the wave
washer resting between the motor bearing
and end bell.
5. Remove the screw (F) that secures the
brush wire.
6. Gently pull the brush (E) out of the brush
holder. Note the position of the return
spring (G) for later replacement.
A
B
C
D
F
E
G
