2 Instruction Descriptions
2-126
NJ-series Instructions Reference Manual (W502)
AccumulationTimer
The AccumulationTimer instruction totals the time that the timer input is TRUE.
* T#0ms to T#106751d_23h47m_16s_854.775807ms
The AccumulationTimer instruction totals the time that the timer input is TRUE. Set the time in nanosec-
onds (ns). The timing accuracy is 100 ns. If reset Reset is FALSE, the timer starts when In changes to
TRUE. Total time ET is incremented as time elapses. The timer stops when In changes to FALSE. ET is
held. When In changes to TRUE again, the timer starts again. ET is incremented from the value that
was previously held. When ET reaches set time PT, timer output Q changes to TRUE. ET is not incre-
mented after that. The timer is reset when Reset changes to TRUE.
ET changes to 0 and Q changes to FALSE.
Instruction Name FB/FUN Graphic expression ST expression
AccumulationTimer Accumulation Timer FB AccumulationTimer_instanc
e(In, PT, Reset, Q, ET);
Variables
Name Meaning I/O Description Valid range Unit Default
In Timer input
Input
TRUE: Timer operates
FALSE: Timer stops
Depends on data type. --- FALSE
PT Set time Maximum time * ms 0
Reset Reset TRUE: Timer reset
FALSE: Timer not reset
Depends on data type. --- FALSE
QTimer
output
Output
TRUE: ET reached PT.
FALSE: ET has not reached
PT.
Depends on data type. ---
---
ET Total time Total time * ms
Boolean
Bit strings Integers
Real
numbers
Times, durations,
dates, and text strings
BOOL
BYTE
WORD
DWORD
LWORD
USINT
UINT
UDINT
ULINT
SINT
INT
DINT
LINT
REAL
LREAL
TIME
DATE
TOD
DT
STRING
In OK
PT OK
Reset OK
QOK
ET OK
Function
AccumulationTimer
In Q
PT ET
Reset
AccumulationTimer_instance
