2-321
2 Instruction Descriptions
NJ-series Instructions Reference Manual (W502)
Data Movement Instructions
2
MoveBit
MoveBit
The MoveBit instruction moves one bit in a bit string.
* If you omit the input parameter, the default value is not applied. A building error will occur.
Instruction Name FB/FUN Graphic expression ST expression
MoveBit Move Bit FUN MoveBit(In, InPos, InOut,
InOutPos);
Variables
Name Meaning I/O Description Valid range Unit Default
In Move
source
Input
Move source Depends on data type.
---
*
InPos Move
source bit
Position of bit in In to move 0 to No. of bits in In − 1
0
InOutPos Move
destination
bit
Position of bit in Out to
receive the bit
0 to No. of bits in InOut
− 1
InOut Move
destination
In-out Move destination Depends on data type.
--- ---
Out Return
value
Output Always TRUE TRUE only --- ---
Boolean
Bit strings Integers
Real
numbers
Times, durations,
dates, and text strings
BOOL
BYTE
WORD
DWORD
LWORD
USINT
UINT
UDINT
ULINT
SINT
INT
DINT
LINT
REAL
LREAL
TIME
DATE
TOD
DT
STRING
In OK OK OK OK
InPos OK
InOutPos OK
InOut OKOKOKOK
Out OK
(@)MoveBit
EN ENO
In Out
InPos
InOut
InOutPos
